Rehabilitation equipment for ailments in the lower extremities
Project Overview
We propose to design a device, much like a leg press, that will aid the patient in strengthening their lower extremities by allowing the patient to lie on their back with their feet pressed against a static solid plate at a 90° angle. The patient can then move by extending their knees. Elastic bands will be used to attain increasing resistance.
As a closed kinetic chain exercise device, our design enables involvement of multiple muscle groups and joints simultaneously. Additionally with the ability to increase the band resistance, a patient may develop their strength over time according to a treatment plan.
Thus, this device will improve productivity of patients’ rehabilitation by gradually strengthening supporting muscle groups.
Team Picture
![Team members from left to right: Amy Slawson, Andrea Shuster, Allena Beroza, Hannah Meyer, Maria Maza](/projects/f12/lower_extremity_device/image/view/7d1c6e2a-7670-47bb-9a8c-895911907274/534706_3768836379836_1255874228_n.jpeg)
Images
![](/projects/f12/lower_extremity_device/image/view/c33c4764-db7b-43fc-a512-900b0ee92c64/conferencephoto.png)
![](/projects/f12/lower_extremity_device/image/view/59a95a8d-110f-4c71-9a80-2ae92e13e0ea/2012-10-07%2011.25.45.png)
![](/projects/f12/lower_extremity_device/image/view/9fec5c57-c2a2-41a3-8501-b369fa5ca7f2/2012-10-07%2011.25.26.png)
![](/projects/f12/lower_extremity_device/image/view/424ca837-3c02-4f15-9f1a-5a657b477073/2012-10-07%2010.45.09.png)
![](/projects/f12/lower_extremity_device/image/view/0fbb834b-b361-41da-b423-2e5eba6e60b3/2012-10-07%2010.51.47.png)
Files
- Final Report (December 12, 2012)
- Final Poster (December 12, 2012)
- Fundraising Letter (October 21, 2012)
- PDS (October 24, 2012)
- Midsemester Report (October 24, 2012)
Contact Information
Team Members
- Hannah Meyer - Team Leader
- Amy Slawson - Communicator
- Andrea Schuster - BSAC
- Maria Maza - BWIG
Advisor and Client
- Prof. Amit Nimunkar - Advisor
- Ms. Karen Patterson - Client
